Description of YHZS75 portable concrete plant
YHZS75 portable concrete plant is a compulsory, high efficient equipment to produce plastic, dry concrete, etc., which is widely used in large and medium-sized construction, road and bridge engineering, the production of commercial concrete ideal equipment.
YHZS75 portable concrete plant, makes the mixing plant movable by gathering batching system, weighing system, mixer, storing system, discharging system and full automatic control system in a towing unit. Adopts forcing type horizontal twin shaft mixer, with characteristics of short mixing time, prompt discharging, uniform mixing, high production efficiency and so on. Suitable for various concrete including plastic concrete, dry concrete and so on. Assure accurate weighing by electronic scale accumulated weighing or individual weighing for aggregate, and scale hopper for cement, water and additive. Microcomputer control assures simple and reliable operation. Key parts of the mixer adopt special processed anti-wear material, also unique shaft end bearing and seal style vastly prolong the mixer service life. YHZS50 portable concrete plant has multiple functions and requires small floor area, suitable for small and medium size mobile construction projects such as water and electricity, roads, ports, airports, bridges and so on.
The Parameters of YHZS75 portable concrete plant
Item |
YHZS75 |
|
theoretical productivity |
75m3/h |
|
weighing scale |
concrete |
3750kg |
|
cement |
900kg |
|
water |
450kg |
|
liquid addictive |
45kg |
overall power |
about 105KW |
|
power source |
380V/50HZ |
|
discharging height |
3.8m |
|
overall weight |
27t(optional parts not included) |
|
trail speed |
≤40km/h |
|
specification |
during work |
18.1x3.6x8.2m |
|
during transportation |
18.6x2.4x4.35m |
YHZS75 portable concrete plant layout
Mixing system
The main machine of YHZS75 portable concrete plant is JS1500 concrete mixer. The mixing system consists of pulley, reducer, open gear, electric motor, mixing drum stirring device and oil supply device. A special sealing device is arranged at the coupling shaft and the two ends of the mixing drum. In order to ensure the quality of the seal, a special oil supply is provided on the end face of the mixer drum.
Batching system
YHZS75 portable concrete plant uses PLD2400 concrete batching machine, which can effectively ensure the accuracy of cement, sand, stone and other mix ratios, and further improve the accuracy of weighing by using electronic weighing system. The top panel of the batching machine produced by Jianxin can be reduced or removed as needed, which can greatly reduce the labor intensity of the loading part and increase the convenience of construction.
Control System
YHZS75 portable concrete plant belt conveyor is an ideal high-efficiency continuous transportation equipment. It has the advantages of long conveying distance, large volume and continuous conveying, and it is reliable in operation, easy to realize automation and centralized control, and easy to disassemble.
