48m HOWO Truck mounted concrete pump
48m HOWO Truck mounted concrete pump is a specially designed product among the middle and short arm pump truck, fill in the blank of truck-mounted concrete boom bump with short and medium jib structure. It is a high efficient concrete conveying equipment integrating driving, pumping, placing. It is equipped with famous brand parts to make the work performance well and stable. It is the best choice for the small and medium projects..
Features of 48m Concrete Pump Truck
1.Original imported GERMANY HBC wireless remote-control device with light weight and handy carrying can enable aggregate carrying pipe to take position accurately simply by manual control.
2.Pumping capacity can be infinitely variably controlled. pump truck expanding speed can be infinitely controlled through quicken-slow device.
3.Boom slewing speed can be infinitely controlled .
4.it’s equipped with emergency brake device and diesel engine auto-control-speed device to lower oil-consumption.original imported GERMANY STEIBEL transfer case and REXROTH pump group;
5.Original imported slewing reducer and slewing motor;original imported GERMANY HAWE proportional multi-way valve;original imported GERMANY REXROTH valve and valve from ITALY oil-control companies;
6.Electric control box adopting totally imported parts while control modules like PLC are all products from GERMANY SIEMENS.
Specifications
name | unit | HDT5291THB-48/5 |
output in theory | m3/h | 125 |
index of the pump carry capacity | Mpa.m3/h | 586 |
Theoretic pumping pressure | Mpa | 8.5 |
bucket volume | L | 700 |
height of top surface of bucket | mm | 1400 |
model of distribution valve | S Valve | |
max. operation radius | m | 43.7 |
max. operation height | m | 47.7 |
max. operation depth | m | 34.3 |
open height of boom | mm | 9065 |
distance between front landing legs | mm | 9780 |
distance between rear landing legs | mm | 9860 |
distance between front & rear landing legs | mm | 9470 |
diameter of delivery pipe | mm | 125 |
length of hose pipe | m | 3 |
rotary range of boom | 365° | |
quantity of boom | 5 | |
rotary angle of each boom | ° | 91/180/180/180/270 |
wire line control distance | m | 33 |
romote control distance | m | 200 |
max. speed | km/h | 85 |
min. turn radius | mm | 12000 |
brake distance | m | 10 |
approach angle | ° | 16 |
departure angle | ° | 11 |
chassis model | HOWO ZZ5437S4667C(HOWO Engine) | |
wheel base between the first & the second axle | mm | 1800 |
wheel base between the second & the third axle | mm | 4600 |
wheel base between the third & the fourth axle | mm | 1350 |
front tread | mm | 2022 |
rear tread | mm | 1830 |
max. engine output power | kw | 275(2200r/min) |
max. engine output torque | n.m | 1500 /(1100~1600 r/min) |
max, gradient ability | % | 37 |
fuel consumption | L/100km | 40 |
(××)out dimension(L×W×H) | mm | 13300×2500×4000 |
total weight | kg | 40000 |
